Product Description

The mixing barrel is driven by a motor V-belt drive to rotate the impeller to fully mix the medicine and slurry evenly, increase the reaction time of the medicine and strengthen the quality of the medicine reaction. This machine is suitable for mineral processing, and can also be used as a stirrer in various chemical industries. . The mixing barrel is suitable for various metal ores. It is mainly used for stirring before flotation to fully mix the reagent and slurry. It can also be used for stirring other non-metallic minerals. It is used for fixed ingredients with a particle size less than 1 mm at a concentration of no more than 30% (by weight). It is in the form of a flat-bottomed barrel-shaped radiation circulation spiral impeller mechanical stirring type.

Product Performance

Working Principle

The mixing barrel is driven by an electric motor V-belt drive to rotate the impeller. Add water and necessary chemicals to the ore during or after grinding to form a slurry in a mixing tank, and then pour it into the slurry tank where the stirring begins. Air is introduced into the slurry to form a large number of bubbles, some of which are not easily wetted by water, i.e. Mineral particles generally called hydrophobic are attached to the bubbles and float to the surface of the slurry together with the bubbles to form a mineralized bubble layer. Other mineral particles that are easily wetted by water, generally called hydrophilic mineral particles, are not attached to the bubbles. while remaining in the slurry, the mineralized bubbles containing specific minerals are discharged to achieve the purpose of mineral processing.

Technical Parameters
